Description
This direct-replacement spin-on engine oil filter is manufactured to original equipment specifications to provide high-efficiency oil filtration, stable hydraulic pressure, and comprehensive internal engine protection. Designed with high-density pleated synthetic blended filter media housed inside a heavy-duty steel casing, it traps abrasive particles, dust, and combustion sludge. Complete with an anti-drainback valve to prevent dry cold starts and a pressure-relief bypass valve to maintain continuous oil flow under high thermal loading, this unit ensures reliable lubrication across every service interval. Replacing a clogged or aged oil filter prevents oil starvation, mitigates camshaft and crankshaft bearing wear, and protects vital engine components.
Compatible Vehicles
Opel Corsa B / C / D 1.0 12V, 1.2 16V, 1.4 16V, 1.6 16V, 1.8 16V (X12XE / Z12XE / Z14XE / Z18XE) (1996–2014)
Opel Corsa Utility Bakkie / Chevrolet Utility 1.4i, 1.6i, 1.8i (8V SOHC / 16V DOHC) (1997–2017)
Opel Astra F / G / H 1.4, 1.6, 1.8, 2.0 16V (X16XEL / Z16XE / Z18XE / C20XE Engines) (1993–2010)
Opel Kadett / Monza 1.3, 1.4, 1.6, 1.8, 2.0 (13S / 14NV / 16SV / 20SEH) (1984–1999)
Opel Meriva A / Tigra B 1.4, 1.6, 1.8 16V (Z14XEP / Z16XE / Z18XE) (2003–2010)
Opel Vectra A / B 1.6, 1.8, 2.0 16V (X16XEL / X18XE / X20XEV) (1995–2002)
Opel Zafira A 1.6, 1.8 16V (X16XEL / Z18XE) (1999–2005)
Chevrolet Aveo 1.4i / 1.6i 16V (F14D3 / F16D3 / L14 Engines) (2003–2011)
Chevrolet Optra 1.6 / 1.8 16V (F16D3 / LDA Engines) (2004–2011)
Chevrolet Spark 0.8 / 1.0 / 1.2 (B10S1 / B12D1 / LA0 Engines) (2003–2015)
Chevrolet Cruze 1.6 / 1.8 16V (F16D4 / 2H0 Petrol) (2009–2016)
Chevrolet Sonic 1.4 / 1.6 (L2N / LDE Petrol Engines) (2011–2017)
Isuzu KB Series KB200 / KB220 2.0i / 2.2i Petrol (4ZE1 / C22NE / 220LE) (1993–2002)
Daewoo Lanos / Cielo / Nubira / Espero 1.4i, 1.5i, 1.6i, 1.8i, 2.0i (A15SMS / A16DMS / C20SED) (1995–2004)
Suzuki Swift II / III 1.0, 1.3, 1.6 (G10 / G13BA / M13A Engines) (1989–2010)
Application Note: Specifically engineered for Opel, Chevrolet, Isuzu, Daewoo, and Suzuki petrol engine applications requiring M18 x 1.5 thread pitch spin-on oil filters. Important Fitment Note: Thoroughly clean the engine block mounting pad and remove any old gasket residue prior to installation. Apply a clean film of fresh engine oil to the filter's rubber sealing gasket. Thread the filter on by hand until the rubber gasket contacts the engine mounting face, then tighten an additional 3/4 to 1 full turn. Do not over-tighten with a filter wrench. Re-check engine oil dipstick levels and run the engine to verify zero oil seepage around the base seal.
Specifications
Part Type: Spin-On Engine Oil Filter
Position: Engine Lubrication System
Part Supplier / Part Number: Z156
Category Code: FIL
Barcode: 6002282000765
OEM Reference Nos: 93156300 / 0650381 / 0650388 / 94797406 / 96458873 / 90541188 / 90028268
Cross-Reference OEM Nos: 93156300 / 0650381 / 0650388 / 94797406 / 96458873 / 90541188 / 90028268 / 93183012
Alternative Part Numbers: GUD Z156 / FRAM PH4722 / MANN W 712/22 / WIX WL7123 / BOSCH 0 451 103 079 / MAHLE OC90 / CHAMPION C130 / PURFLUX LS206
Outer / Can Diameter: 76.0 mm
Overall Height: 89.0 mm
Inner Sealing Diameter: 62.0 mm
Thread Size: M18 x 1.5 mm
Anti-Drainback Valve: Yes
Bypass Relief Valve: Yes
Housing Material: Corrosion-Resistant Heavy-Duty Pressed Steel Housing
